RT 5 - Poulan Pro Rear-Tine Tiller MAINFRAME, LEFT SIDE Parts Diagram

Rear-Tine Tiller

MAINFRAME, LEFT SIDE Parts Diagram

  • Title

1

Poulan 873510500

Nut, Keps 5/16-18 (AYP part number)
(Superseded to 596040501)

$3.99

$

In Stock, Qty 20+

0

2

Poulan 810040600

Washer, Lock 3/8 (AYP part number)
(Superseded to 539990118)

$3.49

$

Usually ships in 3-10 days

0

3

Poulan 873220600

Nut, Hex 3/8-16 (AYP part number)

$6.49

$

In Stock, only 3 left!

0

4

Poulan 874930576

Bolt, Hex 5/16-18 x 4-3/4 (AYP part number)

$4.99

$

Usually ships in 3-10 days

0

5

Poulan 532001572

Pin, Roll (AYP part number)
(Superseded to 532002882)

$6.99

$

Usually ships in 3-10 days

0

6

Poulan 532110111

Lever, Shift

$18.99

$

In Stock, only 1 left!

0

7

Poulan 872110404

Bolt Carriage 1/4-20 x 1/2 Gr. 5 (AYP part number)

$6.49

$

Usually ships in 3-10 days

0

8

Poulan 532008700

Panel, Shift Indicator (AYP part number)

$4.99

$

In Stock, only 1 left!

0

10

Poulan 532086777

Screw, Hex, Washer Head, Slotted #10-24 x 1/2 (AYP part number)
(Superseded to 532750097)

$4.99

$

In Stock, Qty 20+

0

11

Poulan 532009484

Clip (AYP part number)

$6.49

$

In Stock, only 4 left!

0

12

Poulan 810040400

Washer, Lock 1/4 (AYP part number)
(Superseded to 596029801)

$3.99

$

In Stock, only 3 left!

0

13

Poulan 873220400

Nut, Hex 1/4-20 (AYP part number)
(Superseded to 532050675)

$6.49

$

In Stock, only 1 left!

0

14

Poulan 823230506

Screw, Set Hex 5/16-18 x 3/8 (AYP part number)

$4.99

$

In Stock, only 2 left!

0

15

Poulan 532120938

Spacer, Split 0.327 x 0.42 x 2.68 (AYP part number)
(Superseded to 120938X)

$

$

Not available

16

Poulan 819111116

Washer 11/32 x 11/16 x 16 Ga. (AYP part number)
(Superseded to 596204101)

$3.99

$

In Stock, Qty 20+

0

17

Poulan 532100473

Sheave, Transmission (AYP part number)

$

$

Not available

18

Poulan 873220500

Nut, Hex 5/16-18 (AYP part number)

$6.49

$

Usually ships in 3-10 days

0

19

Poulan 532110651

Spacer, Split 0.327 x 0.42 x 1.75 (AYP part number)

$

$

Not available

20

Poulan 532002649

Key, Square 3/16 x 1-1/8 (AYP part number)

$4.99

$

In Stock, only 1 left!

0

21

Poulan 532110653

Guard, Pinch Point (AYP part number)

$

$

Not available

22

Poulan 532110652

Spacer, Split 0.327 x 0.42 x 2.09 (AYP part number)

$5.99

$

Usually ships in 3-10 days

0

23

Poulan 532104214

Nut, Cap 5/16-18 (AYP part number)

$4.99

$

Usually ships in 3-10 days

0

25

Poulan 532102190

Tire (AYP part number)

$93.99

$

Usually ships in 3-10 days

0

Poulan 532124258

Rim (AYP part number)

$122.99

$

Usually ships in 3-10 days

0

Poulan 532124718

Tire Valve (AYP part number)
(Superseded to 532065139)

$10.99

$

In Stock, Qty 20+

0

26

Poulan 532126875

Rivet, Drilled (AYP part number)

$6.49

$

In Stock, Qty 20+

0

27

Poulan 532124788

Clip, Hairpin (AYP part number)
(Superseded to 532004497)

$10.99

$

In Stock, Qty 20+

0

28

Poulan 532124712

Guard, Belt (AYP part number)
(Superseded to 532195793)

$

$

Not available

29

Poulan 532102143

Belt, V (AYP part number)
(Superseded to 532132672)

$34.99

$

In Stock, only 1 left!

0

30

Poulan 532104679

Pulley, Idler (AYP part number)

$18.99

$

In Stock, only 4 left!

0

31

Poulan 812000032

Ring, Klip (AYP part number)

$7.49

$

Usually ships in 3-10 days

0

32

Poulan 532102384

Bolt, Hex 5/16-16 x 12 (AYP part number)

$6.49

$

Usually ships in 3-10 days

0

33

Poulan 532105611

Bracket, Idler (AYP part number)
(Superseded to 532159229)

$

$

Not available

34

Poulan 532102141

Shaft, Idler Arm (AYP part number)

$6.49

$

Usually ships in 3-10 days

0

35

Poulan 874760616

Bolt, Hex 3/8-16 x 1 (AYP part number)
(Superseded to 874780616)

$6.49

$

Usually ships in 3-10 days

0

36

Poulan 532102383

Counterweight, L. H. (AYP part number)

$133.99

$

Usually ships in 3-10 days

0

37

Poulan 874760524

Bolt, Hex 5/16-18 x 1-1/2 (AYP part number)
(Superseded to 74760524)

$2.49

$

Usually ships in 3-10 days

0

38

Poulan 532102331

Bracket, Reinforcement, L.H. (AYP part number)
(Superseded to 584366901)

$4.99

$

Usually ships in 3-10 days

0

39

Poulan 532102142

Sheave, Engine (AYP part number)
(Superseded to 532130816)

$48.99

$

Usually ships in 3-10 days

0

40

Poulan 532102376

Bracket, Guard, Belt (AYP part number)

$

$

Not available

Poulan 532102180

Decal, Shift Indicator (AYP part number)

Note: Not Shown.

$4.99

$

Usually ships in 3-10 days

0

Poulan 532127353

Decal, Belt Guard (AYP part number)

Note: Not Shown.

$

$

Not available
