S6031-KW LP (53AP8DU6750) - Cub Cadet 60" Tank S Zero-Turn Mower, 852cc Kawasaki Propane Bumper Assembly Parts Diagram

60" Tank S Zero-Turn Mower, 852cc Kawasaki Propane

Bumper Assembly Parts Diagram

  • Title

1

Cub Cadet 00010958

Washer, 1/2

$

$

Not available

2

Cub Cadet 00011447

Capscrew, 1/4-20 x 1.00

$

$

Not available

3

Cub Cadet 00012154

Washer, 1/4
(Superseded to 936-3020)

$

$

Not available

4

Cub Cadet 00022560

Flange Lock Nut, 3/8-16
(Superseded to 712-05007)

$3.99

$

In Stock, Qty 20+

0

5

Cub Cadet 00030046

HHCS, 1/2-13, 3.00

$

$

Not available

6

Cub Cadet 00031081

Clamp, 1/2

$5.99

$

Usually ships in 3-6 days

0

7

Cub Cadet 00031602

Carriage Bolt, 1/4-20 x 1.00

$3.49

$

Usually ships in 3-6 days

0

8

Cub Cadet 710-0751

Hex Screw, 1/4-20 x .620

$3.99

$

In Stock, Qty 20+

0

9

Cub Cadet 01001160

Carriage Screw, 1/4-20 x .62

Note: NLA

$

$

Not available

10

Cub Cadet 912-3027

Nut, 1/4-20, Hex Flange Lock

$3.99

$

In Stock, Qty 20+

0

11

Cub Cadet 01004040

Grommet, .75 ID
(Superseded to 735-04285)

$3.99

$

Usually ships in 3-6 days

0

12

Cub Cadet 01008539P

U-Nut, 1/4-20
(Superseded to 726-3054)

$4.49

$

In Stock, Qty 5

0

13

Cub Cadet 710-04064

Capscrew, 1/4-20 x .750

$7.99

$

Usually ships in 3-6 days

0

14

Cub Cadet 680-00079-4021

Bumper Assembly

$

$

Not available

15

Cub Cadet 02004120-0637

Hitch Bracket

$42.99

$

Usually ships in 3-6 days

0

16

Cub Cadet 02004473-0637

Heat Exchanger Assembly

$271.99

$

Usually ships in 3-6 days

0

17

Cub Cadet 02004480

Heat Exchanger Screen

$

$

Not available

18

Cub Cadet 02004481

Fan

$331.99

$

Usually ships in 3-6 days

0

19

Cub Cadet 703-07361-0637

Cooler Mounting Bracket, LH

$

$

Not available

20

Cub Cadet 703-07360-0637

Cooler Mounting Bracket, RH

$

$

Not available

21

Cub Cadet 710-3168

Carriage Bolt, 3/8-16 x 1.00

$3.99

$

In Stock, Qty 20+

0

22

Cub Cadet 712-3083

Hex Nut, 1/2-13, Insert Lock

$4.49

$

In Stock, Qty 20+

0
