SB 45 (59A40051727) - Cub Cadet Yanmar Tractor 45" Snowblower Attachment General Assembly Parts Diagram

Tractor 45" Snowblower Attachment

General Assembly Parts Diagram

  • Title

1

Cub Cadet YS-05244B

Bearing Housing
(Superseded to 05244B)

$22.99

$

In Stock, only 2 left!

0

2

Cub Cadet YS-603-04598

Housing Assembly

$

$

Not available

3

Cub Cadet YS-603-04600

Chute Assembly

$

$

Not available

4

Cub Cadet YS-603-04673

Bracket Assembly

$

$

Not available

5

Cub Cadet YS-603-04689

Chain Cover

$

$

Not available

6

Cub Cadet YS-618-04800

Auger Gear Assembly

$

$

Not available

7

Cub Cadet YS-684-0090B

Impeler Assembly
(Superseded to 684-0090B-0637)

$425.99

$

Usually ships in 3-6 days

0

8

Cub Cadet YS-731-2643

Chute Cleanout Tool
(Superseded to 931-2643)

$18.99

$

In Stock, Qty 8

0

8

Cub Cadet YS-731-2635

Chute Cleanout Tool Mount
(Superseded to 731-11421)

$10.99

$

In Stock, only 2 left!

0

9

Cub Cadet YS-684-04329

Spiral Assembly, RH

$

$

Not available

10

Cub Cadet YS-684-04330

Spiral Assembly, LH

$

$

Not available

11

Cub Cadet YS-703-05048

Rubber Chute Bracket
(Superseded to 703-05048)

$

$

Not available

12

Cub Cadet YS-703-06972

Chute Deflector

$

$

Not available

13

Cub Cadet YS-703-07066

Stand Bracket

$

$

Not available

14

Cub Cadet YS-703-07168

Spacer Plate

$

$

Not available

15

Cub Cadet YS-703-4079

Chute Clamp Spacer
(Superseded to 703-4079-4021)

$

$

Not available

16

Cub Cadet YS-703-4080

Chute Clamp
(Superseded to 703-4080)

$

$

Not available

17

Cub Cadet YS-710-0376

Hex Screw, 5/16-18 x 1.00
(Superseded to 710-0376)

$3.99

$

In Stock, Qty 17

0

18

Cub Cadet YS-710-0451

Carriage Bolt, 5/16-18 x .750
(Superseded to 710-0451)

$3.99

$

In Stock, Qty 20+

0

19

Cub Cadet YS-710-0514

Hex Screw, 3/8-16 x 1.00
(Superseded to 710-0514)

$3.99

$

In Stock, Qty 20+

0

20

Cub Cadet YS-710-0726

Hx. Wshr. Screw, 5/16-20 x .750
(Superseded to 710-0726)

$3.99

$

In Stock, Qty 20+

0

21

Cub Cadet YS-710-0932

Carriage Screw, 1/4-20 x 1.00
(Superseded to 710-0932A)

$3.99

$

In Stock, Qty 5

0

22

Cub Cadet YS-710-0946

Machine Screw, 1/4-20 x .625
(Superseded to 710-0946)

$3.49

$

Usually ships in 3-6 days

0

23

Cub Cadet YS-710-1207

Hex Screw, 5/16-18 x 3.50
(Superseded to 710-1207)

$6.49

$

In Stock, Qty 6

0

24

Cub Cadet YS-710-3008

Hex Screw, 5/16-18 x .75
(Superseded to 710-3008)

$3.99

$

In Stock, Qty 20+

0

25

Cub Cadet YS-710-3015

Hex Screw, 1/4-20 x .75
(Superseded to 710-3015)

$3.99

$

In Stock, Qty 20+

0

26

Cub Cadet YS-710-3038

Hex Screw, 5/16-18 x .875
(Superseded to 710-3038)

$4.49

$

In Stock, Qty 5

0

27

Cub Cadet YS-710-3085

Hex Screw, 3/8-16 x 3.50
(Superseded to 710-3085)

$4.49

$

In Stock, Qty 20+

0

28

Cub Cadet YS-710-3105

Carriage Bolt, 5/16-18 x .875
(Superseded to 710-3105)

$5.99

$

In Stock, Qty 17

0

29

Cub Cadet YS-710-3168

Carriage Bolt, 3/8-16 x 1.00
(Superseded to 710-3168)

$3.99

$

In Stock, Qty 20+

0

30

Cub Cadet YS-710-3178

Carriage Bolt, 3/8-16 x .75
(Superseded to 710-3178)

$3.99

$

In Stock, Qty 20+

0

31

Cub Cadet YS-710-3180

Hex Screw, 5/16-18 x 1.75
(Superseded to 710-3180)

$4.99

$

In Stock, Qty 20+

0

32

Cub Cadet YS-710-3251

Hex Screw, 5/16-18 x 1.75
(Superseded to 710-3251)

$5.99

$

In Stock, Qty 13

0

33

Cub Cadet YS-711-0173

Clevis Pin
(Superseded to 711-04722)

$6.49

$

In Stock, only 3 left!

0

34

Cub Cadet YS-711-05107

Input Shaft

$

$

Not available

35

Cub Cadet YS-712-0130

Hex Lock Nut, 3/8-16
(Superseded to 712-0130)

$3.99

$

In Stock, Qty 20+

0

36

Cub Cadet YS-712-0298

Jam Nut, 1/4-20
(Superseded to 912-0298)

$5.99

$

Usually ships in 3-6 days

0

37

Cub Cadet YS-712-0324

Hex Lock Nut, 1/4-20
(Superseded to 712-0324)

$3.49

$

In Stock, Qty 20+

0

38

Cub Cadet YS-712-3046

Hex Jam Lock Nut,5/16-18 GR8
(Superseded to 712-3046)

Note: Replaces YS-712-04063 Flange Lock Nut, 5/16-18 in this application

$6.49

$

Usually ships in 3-6 days

0

39

Cub Cadet 712-04064

Flange Lock Nut, 1/4-20

$3.99

$

In Stock, Qty 20+

0

40

Cub Cadet YS-712-04065

Flange Lock Nut, 3/8-16
(Superseded to 712-04065)

$3.99

$

In Stock, Qty 20+

0

41

Cub Cadet YS-712-3010

Hex Nut, 5/16-18
(Superseded to 912-3010)

$4.49

$

In Stock, Qty 20+

0

42

Cub Cadet YS-713-04066

Sprocket 15 tooth

$

$

Not available

42

Cub Cadet 759-04259

Sprocket 13 tooth

Note: Optional

$

$

Not available

43

Cub Cadet YS-713-04067

Sprocket

$

$

Not available

44

Cub Cadet YS-713-04068

Roller Chain

$

$

Not available

45

Cub Cadet YS-713-04069

Chain Connecting Link

$

$

Not available

46

Cub Cadet YS-713-04072

Chain Half Link

$

$

Not available

47

Cub Cadet YS-714-0126

Hi-Pro Key
(Superseded to 914-0126)

$4.49

$

In Stock, Qty 20+

0

48

Cub Cadet YS-714-0135

Woodruff Key
(Superseded to 914-0135)

$

$

Not available

49

Cub Cadet YS-714-0145

Click Pin
(Superseded to 914-0145)

$4.49

$

In Stock, Qty 20+

0

50

Cub Cadet YS-714-04040

Bow-Tie Cotter Pin
(Superseded to 714-04040)

$1.49

$

In Stock, Qty 20+

0

51

Cub Cadet YS-714-04059

Hi-Pro Key
(Superseded to 714-04059)

$6.49

$

In Stock, Qty 8

0

52

Cub Cadet YS-714-0507

Cotter Pin
(Superseded to 914-0507)

$4.49

$

In Stock, Qty 19

0

53

Cub Cadet YS-715-0118

Spirol Pin, 5/16-1.75
(Superseded to 915-0118)

$

$

Not available

54

Cub Cadet YS-715-0129

Spirol Pin, .125 x .812
(Superseded to 715-0129)

$4.49

$

In Stock, only 1 left!

0

55

Cub Cadet YS-715-0138

Roll Pin, 1/8 x .63
(Superseded to 915-0138)

$4.49

$

In Stock, only 1 left!

0

56

Cub Cadet YS-715-3003

Spirol Pin
(Superseded to 715-3003)

$6.49

$

In Stock, Qty 11

0

57

Cub Cadet YS-716-0102

Snap Ring
(Superseded to 916-0102)

$4.99

$

In Stock, Qty 20+

0

58

Cub Cadet YS-717-04641

Drive Shaft

$

$

Not available

58

Cub Cadet YS-759-04219

Repair Kit, Yoke Lock
(Superseded to 759-04219)

$90.99

$

Usually ships in 3-6 days

0

59

Cub Cadet YS-720-0201A

Chute Crank Knob
(Superseded to 720-0201A)

$10.99

$

In Stock, Qty 6

0

60

Cub Cadet YS-720-0241

Wing Nut
(Superseded to 720-04072A)

$6.49

$

In Stock, Qty 20+

0

61

Cub Cadet YS-726-0100

Push Cap
(Superseded to 926-0100)

$

$

Not available

63

Cub Cadet YS-731-05163

Spcer., 1.50 OD x 1.00 ID x 1.00
(Superseded to 731-05163)

$6.99

$

In Stock, Qty 20+

0

64

Cub Cadet YS-732-3091

Compression Spring, .57 x 2.09
(Superseded to 732-3091)

$

$

Not available

65

Cub Cadet YS-735-04154

Rubber Deflector

$

$

Not available

66

Cub Cadet YS-736-0105

Washer, .401 x .870 x .063
(Superseded to 736-0105)

$3.99

$

In Stock, Qty 20+

0

67

Cub Cadet YS-736-0123

Flat Washer, .349 x 1.16 x .064
(Superseded to 936-0123)

$5.99

$

Usually ships in 3-6 days

0

68

Cub Cadet YS-736-0140

Flat Washer, .385 x .62 x .063
(Superseded to 936-0140)

$

$

Not available

69

Cub Cadet YS-736-0242

Bell Washer, .340 x .872 x .060
(Superseded to 736-0242)

$3.99

$

In Stock, Qty 20+

0

70

Cub Cadet YS-736-0250

Flat Washer, 1.00 x 1.75 x .107
(Superseded to 736-0250)

$4.49

$

In Stock, Qty 12

0

71

Cub Cadet YS-736-0270

Bell Washer, .265 x .75 x .062
(Superseded to 736-0270)

$3.99

$

In Stock, Qty 15

0

72

Cub Cadet YS-736-0343

Flat Washer, .330 x 1.25 x .120
(Superseded to 736-0343)

$4.49

$

In Stock, Qty 19

0

73

Cub Cadet YS-736-0451

Saddle Wshr., .320 x.93 x .060
(Superseded to 936-0451)

$3.99

$

In Stock, Qty 20+

0

74

Cub Cadet YS-736-3072

Flat Washer, .36 x .93 x .110
(Superseded to 736-3072)

$4.49

$

In Stock, Qty 20+

0

75

Cub Cadet YS-738-0255

Shoulder Screw, .375 x .181
(Superseded to 938-0255)

$4.99

$

In Stock, Qty 12

0

76

Cub Cadet YS-738-04155

Shear Pin, .25 x 1.75
(Superseded to 738-04155)

$1.99

$

In Stock, Qty 20+

0

77

Cub Cadet YS-738-04159

Spiral Axle
(Superseded to 738-04159)

$213.99

$

Usually ships in 3-6 days

0

78

Cub Cadet YS-741-04024

Self-Aligning Bearing
(Superseded to 941-04024)

$60.99

$

In Stock, only 1 left!

0

79

Cub Cadet YS-741-04132A

Self-Aligning Bearing

$

$

Not available

80

Cub Cadet YS-741-0475

Plastic Bushing
(Superseded to 941-0475)

$3.99

$

In Stock, Qty 20+

0

81

Cub Cadet YS-741-0494

Flnge. Bshg., 1.05 ID x 1.16 OD
(Superseded to 741-0494)

$3.99

$

In Stock, only 4 left!

0

82

Cub Cadet YS-747-04188

Chute Crank Rod
(Superseded to 747-04188A)

$

$

Not available

83

Cub Cadet YS-747-0481A

Eye Bolt, 5/16-18 x 3.0
(Superseded to 747-0481A)

$

$

Not available

84

Cub Cadet YS-747-0903

Chute Crank Rod, .375 x 36.75
(Superseded to 747-0903A)

$

$

Not available

85

Cub Cadet YS-747-3427

Front Hitch Pin
(Superseded to 747-3427)

$

$

Not available

86

Cub Cadet YS-749-04549

Crank Support Tube

$

$

Not available

87

Cub Cadet YS-749-04552

Support Tube

$

$

Not available

88

Cub Cadet YS-750-04020

Spacer, 1.004 x 1.375 x .25
(Superseded to 950-04020)

$11.99

$

In Stock, only 1 left!

0

89

Cub Cadet YS-750-05176

Spacer, 3/8 ID x 1.0 x 2.25

$

$

Not available

90

Cub Cadet YS-784-5076

Gear Housing Support Bracket
(Superseded to 784-5076-0637)

$43.99

$

Usually ships in 3-6 days

0

91

Cub Cadet YS-784-5123

Chute Crank Bracket
(Superseded to 784-5123-0637)

$16.99

$

In Stock, only 1 left!

0

92

Cub Cadet YS-784-5149

Bracket Assembly Joint
(Superseded to 684-04350)

$26.99

$

In Stock, only 4 left!

0

93

Cub Cadet YS-784-5401

Chute Crank Assembly
(Superseded to 784-5401A)

$

$

Not available

94

Cub Cadet YS-784-5696B

Shave Plate
(Superseded to 790-00280-0637)

$57.99

$

In Stock, only 1 left!

0

95

Cub Cadet YS-784-5697

Skid Shoe
(Superseded to 784-5697)

$42.99

$

Usually ships in 3-6 days

0

96

Cub Cadet YS-784-5710

Support Plate
(Superseded to 784-5710-0637)

$7.99

$

Usually ships in 3-6 days

0

97

Cub Cadet YS-790-00181

Blade Guide
(Superseded to 790-00181-0637)

$40.99

$

Usually ships in 3-6 days

0
