SC 5627 B - Bear Cat 5" Chipper/Shredder Blower, 627cc Briggs & Stratton (SN: 5VJAA0215HW005514 & Above) Engine Parts Diagram

5" Chipper/Shredder Blower, 627cc Briggs & Stratton

Engine Parts Diagram

  • Title

1

Bear Cat 12446

SHEAVE, 2B3.6 SH, QD

$91.99

$

Usually ships in 3-7 days

0

2

Bear Cat 15005

BOLT, 3/8 X 3/4 GR5 HEX CAPSCREW ZP

$

$

Not available

3

Bear Cat 15031

WASHER, 3/8 FLAT

$

$

Not available

4

15057

BOLT, 3/8-16 X 1 GR5 CRG

$

$

Not available

5

15089

NUT, 1/2 NC ZP JAM

$

$

Not available

6

15133-00

BOLT, 5/16 X 2 FLANGE NC

$

$

Not available

7

Bear Cat 15250

WASHER, 5/16 FLAT

$

$

Not available

8

15285

SETSCREW, 1/2 X 3 SQ HD 1/2 DOG PT

$

$

Not available

9

15314-00

SCREW, #6-32 X 3/4 PAN PHP ZP

$

$

Not available

10

Bear Cat 15381

BOLT, 5/16-24 X 3/4" GR5 HHCS ZP

$0.99

$

Usually ships in 3-7 days

0

11

Bear Cat 15418

KEY, 1/4 SQ X 1-1/2 LG PLAIN

$

$

Not available

12

Bear Cat 15601

NUT, #6-32 NYLON LOCK ZP

$

$

Not available

13

Bear Cat 15904-00

NUT, 5/16-18 NYLOCK FLANGE

$

$

Not available

14

Bear Cat 15905-00

NUT, 3/8-16 NYLOCK FLANGE

$

$

Not available

15

Bear Cat 16378

CLAMP, 15/32 SPRING

$4.49

$

Usually ships in 3-7 days

0

16

16901

BUSHING, SH 1-1/8"

$

$

Not available

17

Bear Cat 31498-00

BELT, 2RB40

$147.99

$

Usually ships in 3-7 days

0

18

Bear Cat 31605-00

METER, TACH/HOUR

$115.99

$

Usually ships in 3-7 days

0

19

33707-00

FITTING, 3/16" X 1/4" VACUUM

$

$

Not available

20

ENGINE, 23 HP BRIGGS (FOR SERVICE SEE ENGINE OWNER'S MANUAL OR NEAREST BRIGGS & STRATTON INDUSTRIAL ENGINE DEALER)

$

$

Not available

21

MUFFLER, BRIGGS 23 HP OIL FILTER SIDE (FOR SERVICE SEE ENGINE OWNER'S MANUAL OR NEAREST BRIGGS & STRATTON INDUSTRIAL ENGINE DEALER)

Note: Mounting hardware included with Item 21

$

$

Not available

22

Bear Cat 36152-00

HOSE ASSEMBLY, CRANKCASE DRAIN

$82.99

$

Usually ships in 3-7 days

0

23

Bear Cat 71379

HOSE, 20" FUEL LINE

$53.99

$

Usually ships in 3-7 days

0

24

73392-12

WELDMENT, ENGINE ADJUSTER

$

$

Not available

25

73394-12

WELDMENT, BELT GUIDE

$

$

Not available

26

73412-12

WELDMENT, SHIELD HEAT

$

$

Not available

27

Bear Cat 76477-00

PAD, FOAM FUEL TANK DAMPER

$24.99

$

Usually ships in 3-7 days

0

Bear Cat 77711-00

ASSEMBLY, FUEL TANK

Note: (INCLUDES ITEMS 28-36)

$448.99

$

Usually ships in 3-7 days

0

28

Bear Cat 18982-00

DECAL, UNLEADED GASOLINE

$5.49

$

Usually ships in 3-7 days

0

29

Bear Cat 32542-00

VALVE, ROLL OVER

$190.99

$

In Stock, only 1 left!

0

30

32822-00

TANK, ROTOMOLDED FUEL

$

$

Not available

31

Bear Cat 32823-00

GAUGE, FUEL LEVEL KELCH 100

$60.99

$

Usually ships in 3-7 days

0

32

Bear Cat 32824-00

CAP, NON-VENTED EPA/CARB APPROVED

$41.99

$

Usually ships in 3-7 days

0

33

Bear Cat 36689-00

GROMMET, TANK FITTING

$3.49

$

Usually ships in 3-7 days

0

34

Bear Cat 36690-00

PLUG, TANK VENT

$10.99

$

Usually ships in 3-7 days

0

35

Bear Cat 36694-00

FITTING, TANK FUEL PICK-UP TUBE

$26.99

$

Usually ships in 3-7 days

0

36

Bear Cat 36696-00

GROMMET, KELCH 100 GAUGE

$8.49

$

Usually ships in 3-7 days

0

Bear Cat 14901-00

CABLE, 24" NEG (R/R)

Note: (NOT SHOWN)

$41.99

$

Usually ships in 3-7 days

0

Bear Cat 17888

CABLE, 33" POS (R/R WITH BOOT)

Note: (NOT SHOWN)

$70.99

$

Usually ships in 3-7 days

0

Bear Cat 33701-00

WIRE ASSEMBLY, ENGINE KILL

Note: (NOT SHOWN)

$69.99

$

Usually ships in 3-7 days

0

33740-00

HARNESS, B&S WIRE

Note: (NOT SHOWN)

$

$

Not available
