SC 5720 B - Bear Cat 5" Chipper/Shredder Blower, 720cc Subaru (SN: 5VJAA0019DW003794 - 5VJAA0211HW005560) Engine Parts Diagram

5" Chipper/Shredder Blower, 720cc Subaru

Engine Parts Diagram

  • Title

1

Bear Cat 12446

SHEAVE, 2B3.6 SH QD

$91.99

$

Usually ships in 3-7 days

0

2

Bear Cat 13599-00

BUSHING, SH 1-7/16

$63.99

$

In Stock, only 1 left!

0

3

Bear Cat 14373-00

HOSE ASSEMBLY, CRANKCASE DRAIN

$81.99

$

Usually ships in 3-7 days

0

4

Bear Cat 14901-00

CABLE, 24" NEG

$41.99

$

Usually ships in 3-7 days

0

5

Bear Cat 15005

BOLT, 3/8 X 3/4 GR5 HEX CAPSCREW ZP

$

$

Not available

6

Bear Cat 15008

BOLT, 3/8 X 2 GR5 HEX CAPSCREW ZP

$

$

Not available

7

Bear Cat 15031

WASHER, 3/8" FLAT ZP

$

$

Not available

8

15057

BOLT, 3/8 X 1" CRG GR5 NC ZP

$

$

Not available

9

15089

NUT, 1/2 NC ZP JAM

$

$

Not available

10

15163-00

BOLT, 3/8 X 1 FLANGE NC

$

$

Not available

11

15285

SETSCREW, 1/2 X 3 SQ HD 1/2 DOG PT

$

$

Not available

12

15397

NUT, 10/24 NYLOCK TYPE NM ZP

$

$

Not available

13

15423

SCREW, MCH 10-24 X 1/2" PAN HD PH ZP

$

$

Not available

14

Bear Cat 15905-00

NUT, 3/8-16 NYLOCK-FLANGE

$

$

Not available

15

Bear Cat 16378

CLAMP, 15/32 SPRING

$4.49

$

Usually ships in 3-7 days

0

16

Bear Cat 17888

CABLE, 33" POS

$70.99

$

Usually ships in 3-7 days

0

17

Bear Cat 31238-00

RELAY, 12V SPDT W/ FLANGE

$61.99

$

Usually ships in 3-7 days

0

18

CONTROL, SUBARU V-TWIN IGNITION

Note: (FOR SERVICE SEE ENGINE OWNER'S MANUAL OR NEAREST AUTHORIZED SUBARU INDUSTRIAL ENGINE DEALER)

$

$

Not available

19

ENGINE, SUBARU 720CC EH72

Note: (FOR SERVICE SEE ENGINE OWNER'S MANUAL OR NEAREST AUTHORIZED SUBARU INDUSTRIAL ENGINE DEALER)

$

$

Not available

20

Bear Cat 31498-00

BELT, 2RB40

$147.99

$

Usually ships in 3-7 days

0

21

Bear Cat 31610-00

HARNESS, CARB SAFETY RELAY

$111.99

$

Usually ships in 3-7 days

0

22

MUFFLER, SUBARU OIL FILTER SIDE

Note: (FOR SERVICE SEE ENGINE OWNER'S MANUAL OR NEAREST AUTHORIZED SUBARU INDUSTRIAL ENGINE DEALER)

$

$

Not available

23

Bear Cat 73079

HOSE, 38" FUEL LINE

$68.99

$

Usually ships in 3-7 days

0

24

Bear Cat 75057-00

HOSE, 43" FUEL LINE

$73.99

$

Usually ships in 3-7 days

0

25

Bear Cat 76477-00

PAD, FOAM FUEL TANK DAMPER

$24.99

$

Usually ships in 3-7 days

0

26

Bear Cat 76865-12

WELDMENT, BELT GUIDE

$54.99

$

Usually ships in 3-7 days

0

27

Bear Cat 76978-12

WELDMENT, ENGINE ADJUSTER

$112.99

$

Usually ships in 3-7 days

0

Bear Cat 77711-00

ASSEMBLY, FUEL TANK

Note: (INCLUDES ITEMS 28-36)

$448.99

$

Usually ships in 3-7 days

0

28

Bear Cat 18982-00

DECAL, UNLEADED GASOLINE

$5.49

$

Usually ships in 3-7 days

0

29

Bear Cat 32542-00

VALVE, ROLL OVER

$190.99

$

In Stock, only 1 left!

0

30

32822-00

TANK, ROTOMOLDED FUEL

$

$

Not available

31

Bear Cat 32823-00

GAUGE, FUEL LEVEL KELCH 100

$60.99

$

Usually ships in 3-7 days

0

32

Bear Cat 32824-00

CAP, NON-VENTED EPA/CARB APPROVED

$41.99

$

Usually ships in 3-7 days

0

33

Bear Cat 36689-00

GROMMET, TANK FITTING

$3.49

$

Usually ships in 3-7 days

0

34

Bear Cat 36690-00

PLUG, TANK VENT

$10.99

$

Usually ships in 3-7 days

0

35

Bear Cat 36694-00

FITTING, TANK FUEL PICK-UP TUBE

$26.99

$

Usually ships in 3-7 days

0

36

Bear Cat 36696-00

GROMMET, KELCH 100 GAUGE

$8.49

$

Usually ships in 3-7 days

0
