Snow Thrower - BCS America 24", 28", 40" Snow Thrower Attachment (1994 & Before) Snow Thrower Gear Box (SN: 45897 - 132623) Parts Diagram

Snow Thrower Attachment

Snow Thrower Gear Box (SN: 45897 - 132623) Parts Diagram

  • Title

1

BCS America 311.11229

SCREW TE M10 X 110

$2.49

$

Usually ships in 5-8 days

0

2

BCS America 311.12082

SCREW M6 X 12

$0.99

$

Usually ships in 5-8 days

0

3

BCS America 31112090

SCREW TE M6 X 16

$0.99

$

In Stock, Qty 10

0

4

BCS America 311.12219

SCREW TE M10 X 25 UNI 5739-8G

$1.49

$

In Stock, Qty 5

0

5

BCS America 311.32563

SCREW TSVEI M6 X 20

$1.99

$

Usually ships in 5-8 days

0

6

BCS America 31211100

NUT M10

$1.49

$

In Stock, only 2 left!

0

7

BCS America 31211160

NUT M16 UNI 5588-5S

$

$

Not available

8

BCS America 312.41061

SELF LOCKING NUT M6

$0.99

$

Usually ships in 5-8 days

0

9

BCS America 313.12159

STUD

$17.99

$

Usually ships in 5-8 days

0

10

BCS America 314.00202

WASHER

$1.49

$

Usually ships in 5-8 days

0

11

BCS America 314.11064

WASHER, FLAT 6.4

$0.99

$

In Stock, only 2 left!

0

12

BCS America 314.21101

SUPER WASHER 10 DIN 6796

$1.99

$

In Stock, Qty 5

0

13

BCS America 314.21252

SUPER WASHER

$5.49

$

Usually ships in 5-8 days

0

14

BCS America 314.22064

WASHER, LOCK 6.4

$0.99

$

Usually ships in 5-8 days

0

15

BCS America 342.11102

PIN, LOCKING 10 X 50 DIN 1481

$1.99

$

In Stock, only 2 left!

0

16

BCS America 351.11062

CIRCLIP, INTERN D 62

$2.49

$

Usually ships in 5-8 days

0

17

BCS America 35121020

CIRCLIP, EXTERN D 20

$1.49

$

In Stock, Qty 8

0

18

BCS America 371.11255

BEARING 25 X 52 X 15 6205

$15.99

$

In Stock, only 1 left!

0

19

BCS America 37111300

BEARING 30 X 62 X 16 6206

$

$

Not available

20

BCS America 37112200

BEARING 20 X 47 X 14 6204 2RS ST

$

$

Not available

21

BCS America 371.12252

BEARING 25 X 47 X 12 ST 2RS 6005

$13.99

$

Usually ships in 5-8 days

0

22

BCS America 38212500

OIL SEAL 25 X 40 X 7

$10.99

$

Usually ships in 5-8 days

0

23

BCS America 382.13004

SEAL, OIL 30 X 62 X 10 STANDARD

$17.99

$

Usually ships in 5-8 days

0

24

BCS America 513.47752

SNOW THROWER CASING

$

$

Currently unavailable

25

BCS America 513.47753

COUPLING

$

$

Currently unavailable

26

BCS America 513.47792

LONG COUPLING

$

$

Currently unavailable

27

BCS America 513.55127

SNOW THROWER LONG CASING

$

$

Currently unavailable

28

BCS America 524.47759

BEVEL GEAR

$184.99

$

Usually ships in 5-8 days

0

29

BCS America 561.42291

WASHER 7 X25 X 4

$1.99

$

Usually ships in 5-8 days

0

30

BCS America 561.47756

SNOW THROWER CASING COVER

$35.99

$

Usually ships in 5-8 days

0

31

BCS America 561.55145

TIEROD

$

$

Currently unavailable

32

BCS America 564.47761

TURBINE SHAFT

$284.99

$

Usually ships in 5-8 days

0

33

BCS America 564.48398

3-TOOTH COUPLING

$48.00

$

Usually ships in 5-8 days

0

34

BCS America 580.47755

SNOW THROWER CASING GASKET

$3.49

$

Usually ships in 5-8 days

0

35

BCS America 581.49267

PLATE

$11.99

$

Usually ships in 5-8 days

0

36

BCS America 581.49269

RUBBER FLAP

$20.99

$

Usually ships in 5-8 days

0

37

BCS America 590.47757

DRIVE SHAFT

$

$

Currently unavailable

38

BCS America 59047780

BLADE 95 CM

$390.99

$

Usually ships in 5-8 days

0

39

BCS America 590.47781

LEFT TURBINE 70 CM

$390.99

$

Usually ships in 5-8 days

0

40

BCS America 590.47834

RIGHT TURBINE 60 CM

$472.99

$

Usually ships in 5-8 days

0

41

BCS America 590.47835

LEFT TURBINE 60 CM

$472.99

$

Usually ships in 5-8 days

0

42

BCS America 590.51045

BREATHER CAP 1/4 GAS

$18.99

$

Usually ships in 5-8 days

0

43

BCS America 590.5513

MAIN SHAFT

$

$

Currently unavailable

44

BCS America 590.55155

LEFT TURBINE 100 CM

$

$

Currently unavailable

45

BCS America 590.55163

RIGHT TURBINE 100 CM

$

$

Currently unavailable
