Speed ZTR 42 CE (966808403) - Dixon 42" Speed ZTR Zero-Turn Mower (2012-01) ACCESSORIES Parts Diagram

42" SpeedZTR Zero-Turn Mower

ACCESSORIES Parts Diagram

  • Title

1

Dixon 539111139

COVER ASSY, COMP

$461.99

$

Usually ships in 3-10 days

0

2

Dixon 532127533

COVER SCREEN

$18.99

$

Usually ships in 3-10 days

0

3

Dixon 532155042

STRIP, REINFORCEMENT

$18.99

$

In Stock, only 2 left!

0

4

Dixon 532130895

LATCH

$7.49

$

In Stock, only 2 left!

0

5

Dixon 532132796

SPRING COVER LH

$6.49

$

In Stock, only 2 left!

0

6

Dixon 532132983

SPRING COVER RH

$6.49

$

In Stock, only 2 left!

0

7

Dixon 532133235

SPACER COVER

$7.49

$

In Stock, only 1 left!

0

8

Dixon 522801301

SPACER PLUG, BAGGER

$7.49

$

Usually ships in 3-10 days

0

9

Dixon 532085902

RETAINER SPRING
(Superseded to 596919601)

$3.99

$

In Stock, Qty 20+

0

10

Dixon 532174083

PLUG, TUBING

$7.49

$

In Stock, only 2 left!

0

11

Dixon 532179746

FRAME ASSEMBLY, 2 BIN

$121.99

$

In Stock, only 1 left!

0

12

Dixon 532128600

HINGE PIN
(Superseded to 532192786)

$12.99

$

Usually ships in 3-10 days

0

13

Dixon 532400226

CONTAINER BAG, SOFT

$87.99

$

In Stock, Qty 20+

0

14

Dixon 532127534

COVER GASKET

$12.99

$

In Stock, Qty 6

0

15

Dixon 539106312

SCREW 10-24 X 3/4

$9.99

$

Usually ships in 3-10 days

0

16

Dixon 539976952

SCREW #10-24 X 5/8
(Superseded to 596039001)

$3.99

$

In Stock, Qty 20+

0

17

Dixon 539108081

SCREW
(Superseded to 818021008)

$6.49

$

In Stock, only 1 left!

0

18

Dixon 539108086

NUT

$4.99

$

In Stock, Qty 20+

0

19

Dixon 539976977

NUT 10-24 NYLOC

$

$

Not available

20

Dixon 539105408

WASHER #10

$3.99

$

In Stock, Qty 12

0
