T 350 - Shindaiwa String Trimmer Gearcase Parts Diagram

String Trimmer

Gearcase Parts Diagram

  • Title

J1-72475-13011

Echo 72475-13011

GEAR CASE ASSY
(Superseded to 72553-63020)

$201.99

$

Usually ships in 2-4 days

0

J2-11022-06280

Echo 11022-06280

SCREW - 6X28
(Superseded to V204000410)

$

$

Not available

J2-22015-13410

Echo 22015-13410

BOLT - 6X10
(Superseded to V206000250)

$1.49

$

In Stock, Qty 18

0

J2-01020-05120

Echo 90010505012

SCREW - 5X12

$1.49

$

In Stock, Qty 15

0

J2-01600-05131

Echo 01600-05131

LOCKWASHER - 5
(Superseded to 90060500005)

$0.99

$

In Stock, only 4 left!

0

J2-01610-05080

Echo 01610-05080

WASHER - 5
(Superseded to 90060000005)

$0.99

$

In Stock, Qty 20+

0

J3-22460-13391

Echo 22460-13391

PINION SET
(Superseded to V651000500)

$29.99

$

Usually ships in 2-4 days

0

J4-02000-06000

Echo 02000-06000

BEARING, BALL - 6000
(Superseded to 90080006000)

$12.99

$

In Stock, only 2 left!

0

J4-22000-13320

Echo 22000-13320

RING, RETAINING
(Superseded to V583000160)

$1.49

$

In Stock, Qty 20+

0

J4-02002-06000

Echo 02002-06000

BEARING, BALL - 6000
(Superseded to 90080406000)

$10.99

$

In Stock, Qty 10

0

J4-02432-26120

Echo 02432-26120

RING, RETAINING - 26
(Superseded to 9242426000)

$1.49

$

In Stock, Qty 5

0

J5-22011-13450

Echo 22011-13450

SHIM
(Superseded to V340000280)

$1.49

$

In Stock, Qty 6

0

J5-02006-06000

Echo 02006-06000

BEARING, BALL - 6000DDU
(Superseded to 90080206000)

$15.99

$

In Stock, Qty 20+

0

J6-22015-13420

Echo 22015-13420

WASHER
(Superseded to V307000230)

$1.49

$

In Stock, only 3 left!

0

J6-22000-13212

Echo 22000-13212

GEAR - SHAFT
(Superseded to C534000610)

$42.99

$

Usually ships in 2-4 days

0

J6-22000-13220

Echo 22000-13220

GEAR - BEVEL
(Superseded to V651000590)

$24.99

$

Usually ships in 2-4 days

0

J7-22000-13241

Echo 22000-13241

HOLDER (A)
(Superseded to C535001010)

$19.99

$

In Stock, only 1 left!

0

J7-22000-13512

Echo 22000-13512

BOLT - 8 -- LEFT HAND
(Superseded to V205000480)

$2.99

$

In Stock, Qty 9

0

J7-22000-13530

Echo 22000-13530

CLIP
(Superseded to V641000150)

$2.99

$

In Stock, Qty 11

0

J7-22000-13252

Echo 22000-13252

HOLDER (B)
(Superseded to 37019-63170)

$17.99

$

In Stock, only 1 left!

0

J7-22000-13290

Echo 22000-13290

GUARD
(Superseded to C535000860)

$2.99

$

In Stock, only 3 left!

0

J8-02432-32120

Echo 02432-32120

RING, RETAINING - 32
(Superseded to 9242432000)

$1.49

$

In Stock, only 4 left!

0

J8-22000-13120

Echo 22000-13120

SEAL, OIL
(Superseded to V510000010)

$5.49

$

In Stock, only 1 left!

0

J8-22000-13230

Echo 22000-13230

COLLAR
(Superseded to V356000500)

$4.49

$

In Stock, only 3 left!

0

J8-02000-06201

Echo 02000-06201

BEARING, BALL - 6201
(Superseded to 90081006201)

$7.99

$

In Stock, only 2 left!

0
