UT-08981 - Homelite Mightylite Backpack Blower, 26cc Figure B Parts Diagram

Mightylite Backpack Blower, 26cc

Figure B Parts Diagram

  • Title

1

Homelite 660466001

Screw (M4 x 18 mm)

$1.49

$

In Stock, Qty 8

0

2

Homelite 518588001

Upper Housing

$

$

Not available

3

Homelite 640098001

Cylinder
(Superseded to 309960001)

$61.99

$

Usually ships in 3-7 days

0

4

Homelite 309960001

Short Block Assembly (Inc. Key Nos. 3 and 5-8)

$61.99

$

Usually ships in 3-7 days

0

5

Homelite 638442003

Cylinder Heat Shield

$1.49

$

In Stock, only 1 left!

0

6

Homelite 660925003

Screw (M4 x 12 mm)

$1.49

$

Usually ships in 3-7 days

0

7

Homelite 638337001

Crankcase Cover
(Superseded to 638337005)

$3.99

$

Usually ships in 3-7 days

0

8

Homelite 901550001

Crankcase Cover Gasket
(Superseded to 901550003)

$1.49

$

In Stock, Qty 5

0

9

Homelite 901551001

Intake Gasket

$1.49

$

In Stock, Qty 17

0

10

Homelite 518497001

Heat Dam

$2.49

$

Usually ships in 3-7 days

0

11

Homelite 518690001

Baffle Plate

$1.49

$

Usually ships in 3-7 days

0

12

Homelite 901552001

Carburetor Gasket

$1.49

$

In Stock, only 1 left!

0

13

Homelite 308054001

Carburetor

$34.99

$

In Stock, only 1 left!

0

14

Homelite 518498001

Air Box Base

$

$

Not available

15

Homelite 660453001

Hex Bolt (Double Sided)

$1.49

$

Usually ships in 3-7 days

0

16

Homelite 660454001

Screw (M5 x 70 mm)

$1.49

$

In Stock, only 3 left!

0

17

Homelite 690969001

Flat Washer

$1.49

$

In Stock, Qty 5

0

18

Homelite 660970003

Screw

$

$

Not available

19

Homelite 308889002

Lower Housing with Starter Assembly (Inc. Key Nos. 20, 26 and 31-35)

$13.99

$

Usually ships in 3-7 days

0

20

Homelite 518502001

Starter Grip

$

$

Not available

21

Homelite 660970001

Screw (M4 x 16 mm)

$1.49

$

In Stock, only 1 left!

0

22

Homelite 660970002

Screw (M4, Special)

$1.49

$

In Stock, Qty 5

0

23

Homelite 308675007

Fuel Tank with Cap Assembly

$7.49

$

Usually ships in 3-7 days

0

24

Homelite 660968001

Screw (M4 x 19 mm)

$1.49

$

Usually ships in 3-7 days

0

25

Homelite 850108001

Ignition Module
(Superseded to 850108002)

$15.99

$

In Stock, only 1 left!

0

26

Homelite 900849002

Starter Rope

$1.49

$

In Stock, only 4 left!

0

27

Homelite 901452003

Muffler Gasket

$1.99

$

Usually ships in 3-7 days

0

28

Homelite 308990016

Muffler Assembly

$28.99

$

Usually ships in 3-7 days

0

29

Homelite 638442001

Heat Shield

$2.99

$

In Stock, only 2 left!

0

30

Homelite 660638003

Screw (10-24)
(Superseded to PS03999)

$

$

Not available

31

Homelite 638033001

Spring & Container Assembly

$3.49

$

Usually ships in 3-7 days

0

32

Homelite 518501001

Starter Pulley

$1.99

$

In Stock, Qty 7

0

33

Homelite 638389001

Pulley Retainer

$1.49

$

In Stock, only 4 left!

0

34

Homelite 650017001

Flat Washer
(Superseded to PS05268)

$1.49

$

In Stock, only 1 left!

0

35

Homelite 660967001

Screw (M4 x 14 mm)

$1.49

$

Usually ships in 3-7 days

0

36

Homelite 308674001

Flywheel Assembly

$15.99

$

Usually ships in 3-7 days

0
