WA20 X C (WA20X) - Honda Water Pump, Made in Japan (SN: WA20X-1000001 - WA20X-9999999) CONTROL Parts Diagram

Water Pump, Made in Japan

CONTROL Parts Diagram

  • Title

1

Honda 16551-ZE0-000

ARM, GOVERNOR

Note: Use up to Engine SN 1290170.

$

$

Not available

1

Honda 16551-ZE0-010

SEE PART DETAILS - PRI; ARM, GOVERNOR

Note: Use from Engine SN 1290171.

$14.99

$

Usually ships in 3-6 days

0

2

Honda 16555-ZE0-000

ROD, GOVERNOR

$5.99

$

Usually ships in 3-6 days

0

3

Honda 16561-ZE0-000

SEE PART DETAILS - SUP; SPRING, GOVERNOR
(Superseded to 16561-ZE0-810)

Note: Use up to Engine SN 1290170.

$4.99

$

In Stock, only 1 left!

0

3

Honda 16561-ZE0-020

SEE PART DETAILS - SUP; SPRING, GOVERNOR
(Superseded to 16561-ZE0-030)

Note: Use from Engine SN 1290171.

$3.49

$

In Stock, Qty 9

0

3

Honda 16561-ZE0-810

SEE PART DETAILS - PRI; SPRING, GOVERNOR

Note: Use up to Engine SN 1290170.

$4.99

$

In Stock, only 1 left!

0

4

Honda 16562-ZE0-000

SPRING, THROTTLE RETURN

Note: Use up to Engine SN 1290170.

$3.99

$

Usually ships in 3-6 days

0

4

Honda 16562-ZE0-020

SPRING, THROTTLE RETURN

Note: Use from Engine SN 1290171.

$3.99

$

In Stock, Qty 7

0

5

Honda 16570-ZE0-000

CONTROL ASSY.

Note: Use up to Engine SN 1290170.

$

$

Not available

5

Honda 16500-ZH7-000

SEE PART DETAILS - PRI; CONTROL ASSY.

Note: Use from Engine SN 2365193.

$34.99

$

Usually ships in 3-6 days

0

5

Honda 16500-ZH7-000

SEE PART DETAILS - PRI; CONTROL ASSY.

Note: Use from Engine SN 1290171 to 2365192.

$34.99

$

Usually ships in 3-6 days

0

6

Honda 16571-ZE0-000

LEVER, CONTROL

Note: Use up to Engine SN 1290556.

$

$

Not available

6

Honda 16571-ZH7-000

LEVER, CONTROL

Note: Use from Engine SN 1290557 to 2365192.

$13.99

$

Usually ships in 3-6 days

0

6

Honda 16571-ZH7-000

LEVER, CONTROL

Note: Use from Engine SN 2365193.

$13.99

$

Usually ships in 3-6 days

0

7

Honda 16574-ZE1-000

SPRING, LEVER

$3.99

$

In Stock, Qty 7

0

8

Honda 16575-ZH8-000

WASHER, CONTROL LEVER

$4.99

$

Usually ships in 3-6 days

0

9

Honda 16578-ZE1-000

SPACER, CONTROL LEVER

$4.99

$

In Stock, Qty 7

0

10

Honda 16581-ZE0-000

BASE, CONTROL

Note: Use up to Engine SN 1290556.

$

$

Not available

10

Honda 16581-ZE0-010

BASE, CONTROL
(Superseded to 16580-ZH7-000)

Note: Use from Engine SN 1290557 to 2365192.

$18.99

$

Usually ships in 3-6 days

0

10

Honda 16580-ZH7-000

BASE, CONTROL

Note: Use from Engine SN 2365193.

$18.99

$

Usually ships in 3-6 days

0

11

Honda 16584-883-300

SPRING, CONTROL ADJUSTING

$4.99

$

In Stock, only 1 left!

0

12

Honda 90013-883-000

BOLT, FLANGE (6X12) (CT200)

$1.99

$

In Stock, Qty 17

0

13

Honda 90022-888-010

BOLT, FLANGE (6X20) (CT200)

$2.99

$

In Stock, only 1 left!

0

14

Honda 90114-SA0-000

SEE PART DETAILS - PRI; NUT, SELF-LOCK (6MM)

Note: Use from Engine SN 1043354.

$3.99

$

In Stock, Qty 14

0

14

Honda 94050-06000

NUT, FLANGE (6MM)

Note: Use up to Engine SN 1043353.

$0.99

$

In Stock, Qty 20+

0

15

Honda 90015-ZE5-010

BOLT, GOVERNOR ARM

Note: Use from Engine SN 1521290.

$2.99

$

In Stock, only 1 left!

0

15

Honda 92101-06020-0A

BOLT, HEX. (6X20)

Note: Use up to Engine SN 1521289.

$1.49

$

Usually ships in 3-6 days

0

16

Honda 93500-05025-0H

SCREW, PAN (5X25)

Note: Use up to Engine SN 2039490.

$0.99

$

In Stock, Qty 5

0

16

Honda 93500-05028-0A

SCREW, PAN (5X28)

Note: Use from Engine SN 2039491.

$1.49

$

In Stock, Qty 5

0

17

Honda 94050-06000

NUT, FLANGE (6MM)

$0.99

$

In Stock, Qty 20+

0
