WH 4817 A (968999106) - Husqvarna 48" Walk-Behind Mower (2000-06) Cutter Housing Assembly Parts Diagram

48" Walk-Behind Mower

Cutter Housing Assembly Parts Diagram

  • Title

1

Husqvarna 539102440

HOUSING ASSEMBLY
(Superseded to 539107418)

Note: (INCLUDES ITEMS 2 THRU 7) This Housing Assembly (item 1) will not work if these items are not in their proper location or orientation.

$

$

Not available

2

Husqvarna 539102675

MACHINERY BUSHING 10 GA.

$11.99

$

In Stock, only 3 left!

0

3

Husqvarna 539102244

BUSHING.MACHINE.18.GAUGE

Note: Must set against the inner race of the bearing, top & bottom.

$

$

Not available

4

Husqvarna 539102677

BEARING
(Superseded to 539115279)

$35.99

$

In Stock, only 1 left!

0

5

Husqvarna 539102673

HOUSING

$

$

Not available

6

Husqvarna 539102676

SPACER

$10.99

$

In Stock, Qty 14

0

7

Husqvarna 539102674

SPINDLE SHAFT

$

$

Not available

8

Husqvarna 539976398

PULLEY W/SETSCREWS

$

$

Not available

9

Husqvarna 539101819

PULLEY, DOUBLE W/SETS

$227.99

$

Usually ships in 3-10 days

0

10

Husqvarna 539102245

SPACER

$

$

Not available

11

Husqvarna 539102243

WASHER, SUPPORT
(Superseded to 596437501)

$11.99

$

In Stock, only 2 left!

0

12

Husqvarna 539101995

KEY 1/4 SQ X 1 1/8

$

$

Not available

13

Husqvarna 539976956

SET SCREW 5/16 NYLOC

$

$

Not available
