YTH 180 (954001082-B) - Husqvarna Yard Tractor (1994-12) Drive Parts Diagram

Yard Tractor

Drive Parts Diagram

  • Title

1

Husqvarna 532145605

Transaxle 6sp Dana LT Model #4360-96
(Superseded to 532170269)

$

$

Not available

2

Husqvarna 532146682

Spring Return Brake

$8.99

$

In Stock, only 1 left!

0

3

Husqvarna 532123666

Pulley Transaxle 20" tires

$37.99

$

In Stock, only 3 left!

0

4

Husqvarna 812000028

Ring Retainer # 5100-62

$7.49

$

In Stock, Qty 17

0

5

Husqvarna 532121520

Strap Torque 30 Degrees

$7.49

$

In Stock, only 3 left!

0

6

Husqvarna 817490512

Screw Thdrol 5/16-18 X 3/4 TYT
(Superseded to 874780512)

$3.99

$

In Stock, Qty 20+

0

8

Husqvarna 532141002

Rod Shifter

$

$

Not available

9

Husqvarna 532137140

Clutch Electric
(Superseded to 532142600)

$

$

Not available

10

Husqvarna 876020416

Pin Cotter 1/8 X 1 Cad

$3.99

$

Usually ships in 3-10 days

0

11

Husqvarna 532105701

Washer Plate Shf 388 Sq Hole

$6.49

$

In Stock, only 1 left!

0

12

Husqvarna 819151216

Washer 15/32 X 3/4 X 16 Ga

$

$

Not available

13

Husqvarna 874550412

Bolt 1/4-28 unf Gr 8 w/Patch
(Superseded to 871040412)

$6.49

$

Usually ships in 3-10 days

0

14

Husqvarna 810040400

Washer Lock Hvy Helical 1/4
(Superseded to 596029801)

$3.99

$

In Stock, only 3 left!

0

15

Husqvarna 874780544

Bolt Fin Hex 5/16-18uncx 2 3/4

$

$

Not available

17

Husqvarna 532126197

Washer 1-1/2 OD X 15/32 ID X .250

$8.99

$

In Stock, Qty 20+

0

18

Husqvarna 874780616

Bolt Fin Hex 3/8-16unc X 1 Gr. 5

$6.49

$

Usually ships in 3-10 days

0

19

Husqvarna 873800600

Nut Lock 3/8-16 Unc
(Superseded to 873680600)

$3.99

$

Usually ships in 3-10 days

0

20

Husqvarna 871170768

Bolt, Hex 7/16-20 x 4-1/4
(Superseded to 532150280)

$4.99

$

In Stock, Qty 11

0

21

Husqvarna 532121274

Knob Duckhead 3/8-16unc Blk

$8.99

$

Usually ships in 3-10 days

0

22

Husqvarna 532130804

Rod Brake Blk Zinc 27 326

$31.99

$

Usually ships in 3-10 days

0

23

Husqvarna 532137141

Bracket Asm. Clutch

$

$

Not available

24

Husqvarna 873350600

Nut Hex Jam 3/8-16 Unc
(Superseded to 873220600)

$6.49

$

In Stock, only 4 left!

0

25

Husqvarna 532106888

Spring Rod Brake 2 00 Zinc
(Superseded to 532151332)

$6.49

$

In Stock, Qty 6

0

26

Husqvarna 819131316

Washer 13/32 X 13/16 X 16 Ga
(Superseded to 596565301)

$3.99

$

In Stock, Qty 20+

0

27

Husqvarna 876020412

Pin Cotter 1/8 X 3/4 Cad
(Superseded to 539990365)

$6.49

$

In Stock, Qty 20+

0

28

Husqvarna 532145204

Rod Brake Parking

$

$

Not available

29

Husqvarna 532071673

Cap Brake Parking Black

$4.99

$

In Stock, only 1 left!

0

30

Husqvarna 532130807

Bracket Mtg Transaxle

$3.99

$

Usually ships in 3-10 days

0

31

Husqvarna 532127275

Keeper Belt LH LT 14 Ga

$

$

Not available

32

Husqvarna 874760512

Bolt Hex Hd 5/16-18unc X 3/4
(Superseded to 874780512)

$3.99

$

In Stock, Qty 20+

0

33

Husqvarna 872140506

Bolt, Carriage 5/16-18 x 3/4
(Superseded to 595901601)

$3.99

$

In Stock, Qty 20+

0

34

Husqvarna 532149001

Shaft Asm Pedal Foot

$34.99

$

Usually ships in 3-10 days

0

35

Husqvarna 532120183

Bearing Nylon Blk 629 Id

$6.49

$

In Stock, Qty 7

0

36

Husqvarna 819211616

Washer 21/32 X 1 X 16 Ga

$6.49

$

Usually ships in 3-10 days

0

37

Husqvarna 532124963

Pin Roll 3/16 X 1"
(Superseded to 532002882)

$6.99

$

Usually ships in 3-10 days

0

38

Husqvarna 532123674

Pulley Idler Flat

$31.99

$

In Stock, only 2 left!

0

39

Husqvarna 874760644

Bolt Fin Hex 3/8-16unc X 2-3/4

$6.49

$

Usually ships in 3-10 days

0

40

Husqvarna 532124965

Spacer Split 395 X 59 Bzp

$6.49

$

Usually ships in 3-10 days

0

41

Husqvarna 532109070

Keeper Belt Retainer

$6.49

$

Usually ships in 3-10 days

0

42

Husqvarna 819131312

Washer 13/32 X 13/16 X 12 Ga
(Superseded to 734117201)

$3.49

$

In Stock, Qty 20+

0

43

Husqvarna 819111012

Washer 11/32 x 5/8 x 12 Ga.

$6.49

$

Usually ships in 3-10 days

0

44

Husqvarna 532105706

Bearing Nyl 503 X 628 X 1 25

$7.49

$

Usually ships in 3-10 days

0

45

Husqvarna 532110812

Washer Hardened

$

$

Not available

46

Husqvarna 812000039

Ring Klip #t5304-50

$6.49

$

In Stock, Qty 13

0

47

Husqvarna 532127783

Pulley Idler V Groove Plastic
(Superseded to 532139245)

$34.99

$

In Stock, Qty 8

0

48

Husqvarna 532123789

Bellcrank Asm Clutch

$

$

Not available

49

Husqvarna 532123205

Retainer Belt Style Spring

$6.49

$

Usually ships in 3-10 days

0

50

Husqvarna 874760624

Bolt Hex Hd 3/8-16unc X 1-1/2
(Superseded to 874930624)

$

$

Not available

51

Husqvarna 873680600

Nut Crownlock 3/8-16 Unc

$3.99

$

Usually ships in 3-10 days

0

52

Husqvarna 873680500

Nut Crownlock 5/16 - 18
(Superseded to 873690500)

$3.99

$

Usually ships in 3-10 days

0

53

Husqvarna 532105710

Link Clutch 7 66
(Superseded to 532199652)

$13.99

$

Usually ships in 3-10 days

0

54

Husqvarna 532124996

Clip Fuel Line 13/32 Mtg. Hole
(Superseded to 532002751)

$

$

Not available

55

Husqvarna 532105709

Spring Return Clutch 6 75

$10.99

$

In Stock, Qty 20+

0

56

Husqvarna 874760620

Bolt Fin Hex 3/8-16unc X 1-1/4

$7.49

$

In Stock, only 3 left!

0

57

Husqvarna 532130801

V-Belt Ground Drive 95 25 42"
(Superseded to 532138255)

$36.99

$

In Stock, Qty 18

0

58

Husqvarna 532127274

Keeper Belt RH LT Pnt/zinc 16g

$4.99

$

Usually ships in 3-10 days

0

59

Husqvarna 532140312

Keeper Belt Chassis Span Ctr
(Superseded to 532169691)

$26.99

$

Usually ships in 3-10 days

0

60

Husqvarna 532121218

Keeper Belt Engine LH LT

$

$

Not available

61

Husqvarna 817490612

Screw Thdrol 3/8-16x3/4 Ty-tt
(Superseded to 874780612)

$7.49

$

In Stock, only 2 left!

0

62

Husqvarna 532123533

Cover Pedal Premuim

$6.99

$

Usually ships in 3-10 days

0

63

Husqvarna 532140189

Engine Pulley LT/YT

$42.99

$

Usually ships in 3-10 days

0

65

Husqvarna 810040700

Washer Lock Hvy Hlcl Spr 7/16
(Superseded to 539990247)

$

$

Not available

68

Husqvarna 532105730

Keeper Belt Engine BZP Zinc

$4.99

$

Usually ships in 3-10 days

0

74

Husqvarna 532109502

Spacer Split

$

$

Not available

75

Husqvarna 532121749

Washer 25/32 X 1 1/4 X 16 Ga

$3.49

$

In Stock, Qty 20+

0

76

Husqvarna 812000001

E-ring #5133-75

$4.99

$

In Stock, Qty 20+

0

77

Husqvarna 532123583

Key Square 2 0 X 1845/ 1865

$4.99

$

In Stock, only 4 left!

0

78

Husqvarna 532121748

Washer 25/32 X 1-5/8 X 16 Ga

$3.49

$

In Stock, Qty 20+

0

80

Husqvarna 532131487

Arm Shift Transaxle

$

$

Not available

81

Husqvarna 532136933

Shaft Asm Cross 20"t 42" deck
(Superseded to 532161077)

$

$

Not available

82

Husqvarna 532123782

Spring Torsion T/a

$

$

Not available

83

Husqvarna 819171216

Washer 17/32 X 3/4 X 16 Ga
(Superseded to 734117771)

$6.49

$

In Stock, only 3 left!

0

84

Husqvarna 532132183

Rod Tie Shift Adj Ball

$60.99

$

Usually ships in 3-10 days

0

85

Husqvarna 873530400

Nut Nylock 1/4-28
(Superseded to 873610400)

$

$

Not available

86

Husqvarna 532071208

Bushing Rod Strg 629/632 Id

$3.99

$

Usually ships in 3-10 days

0

87

Husqvarna 819212016

Washer 21/32 X 1-1/4 X 16 Ga

$6.49

$

Usually ships in 3-10 days

0

88

Husqvarna 812000008

Ring Klip #5304-62

$6.49

$

Usually ships in 3-10 days

0

89

Husqvarna 532139991

Console Shift 6sp W/ign LT

$

$

Not available

90

Husqvarna 532124346

Nut Self-thd wsh-hd 1/4 zinc

$4.99

$

In Stock, only 1 left!

0

100

Husqvarna 819111216

Washer 11/32 x 3/4 x 16 Ga.
(Superseded to 734116301)

$3.99

$

In Stock, Qty 20+

0
