ZTR 6023 - Dixon Zero-Turn Mower (2002) OIL RESERVOIR, HOSES & FITTINGS Parts Diagram

Zero-Turn Mower

OIL RESERVOIR, HOSES & FITTINGS Parts Diagram

  • Title
3020

3020

5/16STD FLAT WASHER.

$

$

Not available

3023

3023

1/4HELICAL L-WASHER

$

$

Not available

3087

3087

5/16-18X3/4 HHB GR5

$

$

Not available

3205

3205

5/16-18 HX NUT W/NY.

$

$

Not available

3258

3258

5/16-18X4-1/2 HHB GR8

$

$

Not available

3717

3717

CLAMP 3/8

$

$

Not available

7252

7252

R/B 7252 FILTER

$

$

Not available

8394

8394

3/8` HOSE - 21`

$

$

Not available

12446

12446

3/8` HOSE - 14`

$

$

Not available

60028

60028

ADAPTER 7/16 SAE X 1/4

$

$

Not available

60123

60123

TANK MOUNTING BRACKET

$

$

Not available

60124

60124

SPACER

$

$

Not available

60214

60214

CAPSCREW HX 1/4-20X5/8

$

$

Not available

60299

60299

HOSE BARB 90 EL 1/4 NPTM

$

$

Not available

60308

60308

BLIND HOLE KURLY-LOC

$

$

Not available

60310

60310

ADAPTER 7/8-14 M. TO 1/

$

$

Not available

60315

60315

TEE 1/4NPT X 3/8 X 3/8

$

$

Not available

60317

60317

FILTER HEAD 1/4 NPT

$

$

Not available

60330

60330

TANK 3 QT.

$

$

Not available

60334

60334

CAP OPEN COVERED VENT

$

$

Not available

60373

60373

BARB 3/8` HOSE 1/4` NPT

$

$

Not available
