CV490-27532 - Kohler Command PRO Engine, Made for EHP/Sears, 17hp, 12.7kW Crankcase 2-27-77 Parts Diagram

Command PRO Engine, Made for EHP/Sears, 17hp, 12.7kW

Crankcase 2-27-77 Parts Diagram

  • Title

1

Kohler 12 032 03-S

SEAL, OIL

$12.99

$

Usually ships in 2-5 days

0

2

CRANKCASE

Note: (USE: Short Block 12 522 51)

$

$

Not available

3

Kohler 12 445 02-S

STRAP

$17.99

$

Usually ships in 2-5 days

0

4

Kohler M-839025-S

SCREW, FLG M8X1.25X25

$2.49

$

Usually ships in 2-5 days

0

5

Kohler 24 380 16-S

PIN, LOCATING

$4.49

$

In Stock, only 3 left!

0

6

Kohler 12 010 31-S

CAMSHAFT ASSEMBLY - DISCONTINUED

$

$

Not available

7

Kohler 12 422 08-S

SHIM, CAMSHAFT (BLUE .03")

Note: (A.R.)

$2.49

$

In Stock, only 2 left!

0

1242209-S

Kohler 12 422 09-S

SHIM, CAMSHAFT (RED .032")

Note: (A.R.)

$2.49

$

In Stock, only 1 left!

0

1242210-S

Kohler 12 422 10-S

SHIM, CAMSHAFT (YELLOW .034")

Note: (A.R.)

$2.49

$

In Stock, Qty 11

0

1242211-S

Kohler 12 422 11-S

SHIM, CAMSHAFT (GREEN .036")

Note: (A.R.)

$2.49

$

Usually ships in 2-5 days

0

1242212-S

Kohler 12 422 12-S

SHIM, CAMSHAFT (GRAY .038")

Note: (A.R.)

$2.99

$

Usually ships in 2-5 days

0

1242213-S

Kohler 12 422 13-S

SHIM, CAMSHAFT (BLACK .04")

Note: (A.R.)

$2.99

$

Usually ships in 2-5 days

0

1242207-S

Kohler 12 422 07-S

SHIM, CAMSHAFT (WHITE .028")

Note: (A.R.)

$4.49

$

In Stock, only 2 left!

0

8

Kohler 12 144 28-S

SHAFT, BALANCE

$109.99

$

Usually ships in 2-5 days

0

9

Kohler 12 874 07-S

KIT, PISTON W/RING SET (STD)

Note: (Includes 10,11)

$174.99

$

Usually ships in 2-5 days

0

1287411-S

Kohler 12 874 11-S

KIT, PISTON W/RING SET (.08) - DISCONTINUED

Note: (.08) (Includes 10,11)

$

$

Not available

1287408-S

Kohler 12 874 08-S

KIT, PISTON W/RING SET (.25) - DISCONTINUED

Note: (Includes 10,11)

$

$

Not available

1287409-S

Kohler 12 874 09-S

KIT, PISTON W/RING SET (.50)

Note: (Includes 10,11)

$

$

Not available

10

Kohler 12 018 02-S

RETAINER

$3.49

$

Usually ships in 2-5 days

0

11

Kohler 12 108 07-S

RING SET (STD & .08)

Note: (Std. & .08)

$90.99

$

In Stock, only 4 left!

0

1210808-S

Kohler 12 108 08-S

RING SET (.25)

$121.99

$

Usually ships in 2-5 days

0

1210809-S

Kohler 12 108 09-S

RING SET (.50) - DISCONTINUED

$

$

Not available

12

Kohler 12 067 11-S

ROD ASSY, CONNECTING (STD)

$80.99

$

In Stock, only 4 left!

0

1206712-S

Kohler 12 067 12-S

ROD ASSY, CONNECTING(.25)

$73.99

$

Usually ships in 2-5 days

0

13

Kohler 12 380 01-S

PIN, GOVERNOR REGULATING

$3.49

$

In Stock, Qty 20+

0

14

Kohler 12 043 05-S

GOVERNOR GEAR ASSEMBLY

$25.99

$

In Stock, Qty 10

0

15

Kohler M-631005-S

WASHER, FLAT 6 MM

$2.49

$

In Stock, Qty 7

0

16

Kohler 12 144 02-S

SHAFT, GOVERNOR GEAR

$6.49

$

In Stock, Qty 13

0

17

Kohler 52 139 09-S

PLUG, CUP

$4.99

$

In Stock, Qty 10

0

18

Kohler 12 755 64-S

KIT, GOVERNOR CROSS SHAFT

Note: (includes 19)

$12.99

$

In Stock, only 4 left!

0

19

Kohler 12 154 05-S

CLIP, HITCH PIN

$2.49

$

Usually ships in 2-5 days

0

20

Kohler M-631015-S

WASHER, FLAT 6 MM

$2.49

$

In Stock, Qty 6

0

21

Kohler 12 032 01-S

SEAL, GOVERNOR CROSS SHAFT

$6.49

$

In Stock, Qty 20+

0

22

Kohler X-25-102-S

WASHER, FLAT 1/4"

$2.49

$

In Stock, only 3 left!

0
