PRO2.0iS (PRO20iS-3001) - Kohler PRO 2,000 Watt Inverter Generator Frame Parts Diagram

PRO 2,000 Watt Inverter Generator

Frame Parts Diagram

  • Title

1

Kohler 33 094 02-S

BASE, AIR CLEANER - MOUNTING

$83.99

$

Usually ships in 2-5 days

0

2

Kohler 33 366 03-S

MOUNT, INSULATOR

$6.99

$

Usually ships in 2-5 days

0

3

Kohler 25 086 525-S

SCREW - BOLT W/WASHER

$3.99

$

Usually ships in 2-5 days

0

4

Kohler 33 241 01-S

COLLAR

$4.99

$

Usually ships in 2-5 days

0

5

Kohler 33 100 09-S

NUT, FLANGE

$3.99

$

Usually ships in 2-5 days

0

6

Kohler 33 100 17-S

NUT, FLANGE

$4.49

$

Usually ships in 2-5 days

0

7

Kohler 33 366 04-S

MOUNT, INSULATOR

$27.99

$

Usually ships in 2-5 days

0

8

Kohler 33 100 09-S

NUT, FLANGE

$3.99

$

Usually ships in 2-5 days

0

9

Kohler 33 263 06-S

DAMPER, STOPPER

$4.49

$

Usually ships in 2-5 days

0

10

Kohler 33 384 01-S

ISOLATOR, VIBRATION DAMPER SHOCK ABSORBE

$3.99

$

Usually ships in 2-5 days

0

11

Kohler 33 146 07-S

PLATE, DAMPER

$3.99

$

Usually ships in 2-5 days

0

12

Kohler 33 096 09-S

COVER, AIR CLEANER - FRONT

$43.99

$

Usually ships in 2-5 days

0

13

Kohler 33 032 15-S

SEAL 1

$5.49

$

Usually ships in 2-5 days

0

14

Kohler 33 100 17-S

NUT, FLANGE

$4.49

$

Usually ships in 2-5 days

0

15

Kohler 33 531 01-S

STOPPER

$4.49

$

Usually ships in 2-5 days

0

16

Kohler 33 263 08-S

DAMPER, PLATE

$8.99

$

Usually ships in 2-5 days

0

17

Kohler 33 096 10-S

COVER, AIR CLEANER - COVER ASSY 2

$50.99

$

Usually ships in 2-5 days

0

18

Kohler 33 032 16-S

SEAL 2

$3.99

$

Usually ships in 2-5 days

0

19

Kohler 33 032 17-S

SEAL 3

$5.49

$

Usually ships in 2-5 days

0

20

Kohler 33 263 10-S

DAMPER, PLATE

$8.99

$

Usually ships in 2-5 days

0

21

Kohler 25 086 512-S

SCREW - TAPPING

$3.99

$

Usually ships in 2-5 days

0

22

Kohler 33 100 19-S

NUT, SPRING

$4.49

$

Usually ships in 2-5 days

0

23

Kohler 33 096 11-S

COVER, AIR CLEANER - COVER DUST SEAL 1

$3.99

$

Usually ships in 2-5 days

0

24

Kohler 33 263 07-S

DAMPER, PLATE

$3.99

$

Usually ships in 2-5 days

0

25

Kohler 33 263 12-S

DAMPER, PLATE

$8.99

$

Usually ships in 2-5 days

0

26

Kohler 33 100 18-S

NUT, SQUARE

$3.99

$

Usually ships in 2-5 days

0

27

Kohler 25 086 478-S

SCREW - BOLT FLANGE

$3.99

$

Usually ships in 2-5 days

0

28

Kohler 33 126 06-S

BRACKET, FUEL TANK

$85.99

$

Usually ships in 2-5 days

0

29

Kohler 25 086 493-S

SCREW - BOLT FLANGE

$3.99

$

Usually ships in 2-5 days

0

30

Kohler 33 313 05-S

GROMMET

$6.49

$

Usually ships in 2-5 days

0

31

Kohler 33 313 06-S

GROMMET

$8.99

$

Usually ships in 2-5 days

0

32

Kohler 33 403 02-S

RECTIFIER ASSEMBLY

$46.99

$

Usually ships in 2-5 days

0

33

Kohler 25 086 532-S

SCREW - PAN HEAD

$5.49

$

Usually ships in 2-5 days

0

34

Kohler 33 225 02-S

CABLE ASSEMBLY, STARTER

$23.99

$

Usually ships in 2-5 days

0

35

Kohler 33 468 12-S

WASHER, PLATE

$4.49

$

Usually ships in 2-5 days

0

36

Kohler 25 086 527-S

SCREW - BOLT

$5.49

$

Usually ships in 2-5 days

0

37

Kohler 33 761 02-S

KIT, TOOL

$15.99

$

Usually ships in 2-5 days

0
